NVJ635MF Series |
|
Model |
NVJ635MF |
|
Image Sensor |
1/2.8" CMOS Sensor |
|
Effective Pixels |
5 megapixels |
|
Electronic Shutter |
AUTO, 1/25s ~ 1/100000s |
|
Min. Illumination |
0.01Lux@F1.2(AGC ON), 0Lux IR on |
|
Day/Night |
Auto/Color/(B/W)/Timing |
|
WDR |
Digital WDR |
|
White Balance |
Auto/Manual |
|
BLC /HLC |
Support |
|
DNR |
2D/3D DNR |
|
Other Camera Parameter |
AGC,Motion Detection,Privacy Mask,Flip,Rotate,RIO,OSD overlay |
|
Video Standard |
H.264/H.265 |
|
Video Resolution |
Main Stream:30fps@ 5MP(2592*1944) , 30fps@ 4MP(2592*1520) Sub Stream: D1/VGA(640x480)/360P/QVGA@30fps |
|
Video Bitrates |
512Kbps - 12Mbps, VBR/CBR |
|
Audio Standard |
G.711-u/G.711-a |
|
Built-in Mic |
Optional |
|
OSD Overlay |
Title and Time overlay ,custom color adjustable |
|
IR Led |
18 pcs SMD array IR Led |
|
IR Distance |
30 M |
|
Focal length |
3.6 mm fixed lens |
|
Optional Function |
PoE, Audio |
|
Protocol |
HTTP/RTSP/FTP/SMTP/DHCP/NTP/NFS, etc. |
|
P2P |
Yes |
|
Web |
IE , Firefox (32bit esr), etc. |
|
Media |
CMS, Android, IOS |
|
ONVIF |
17.06 compatible |
|
Network Port |
1-RJ45, 100Mbps, POE optional |
|
Power Supply |
12 VDC ± 10% |
|
Power Consumption |
< 8 W |
|
Operating Temp. |
-30℃-(+60)℃, 10%-90%RH |
|
