NVJ695F-PTZ3X Series |
|
Image Sensor |
1/2.8" Sony IMX335 CMOS |
|
Effective Pixels |
2592(H)×1944 (V) |
|
Electronic Shutter |
AUTO, 1/25s ~ 1/100000s |
|
Min. Illumination |
0.01Lux@F1.2(AGC ON), 0Lux IR on |
|
Day/Night |
Auto/Color/(B/W)/Timing |
|
WDR |
Digital WDR |
|
White Balance |
Auto |
|
Other |
AGC,2/3 DNR,Motion Detection, Privacy Mask, Mirror, Flip |
|
Embedded Solution |
SSC337DE |
|
Video Standard |
H.265/H.264 |
|
Video Resolution |
Main Stream: 25fps@5MP(2592x1944)/4MP(2592x1520)/3MP, 30fps@1080P/720P Sub stream: 25fps@D1/VGA/360P/CIF, etc |
|
Video Bitrates |
512Kbps - 8Mbps, VBR/CBR |
|
IR Led |
3 pcs SMD Array IR Leds |
|
IR Distance |
30 M |
|
Focal length |
2.8-8 mm AF Motorized lens |
|
Zoom |
3x optical zoom |
|
Pan/Tilt Range |
Pan: 0° ~ 350°; Tilt: 5° ~ 90° |
|
Manual Control Speed |
80°/Sec |
|
POE |
Internal POE |
|
Audio |
Internal Microphone |
|
Reset |
Cable with reset button |
|
Protocol |
RTSP/FTP/DHCP/DDNS/NTP/SMTP/NFS |
|
P2P |
Yes |
|
Web |
IE , firefox 32bit ESR |
|
Media |
CMS, Android, IOS |
|
ONVIF |
17.06 compatible |
|
Network Port |
1-RJ45, 100Mbps, POE optional |
|
Power Supply |
12 VDC ± 10% |
|
Power Consumption |
< 5 W |
|
Operating Temp. |
-30℃-(+60)℃, 10%-90%RH |
|
