NVJ575F-PTZ4X Series |
|
Model |
NVJ575F-PTZ4X |
|
Image Sensor |
1/2.8" CMOS |
|
Effective Pixels |
5 megapixels |
|
Electronic Shutter |
AUTO |
|
Min.Illumination |
0.01Lux@F1.2(AGC ON), 0Lux IR on |
|
Day/Night |
Auto/Color/(B/W)/Timing |
|
WDR |
Digital WDR |
|
White Balance |
Auto/Manual |
|
AGC/BLC |
Support |
|
DNR |
2D/3D DNR |
|
Other |
Multi-lines OSD, Motion Detection, Privacy Mask, Mirror, Flip |
|
Video Standard |
H.265/H.264 |
|
Video Resolution |
Main Stream: 15fps@5MP(2592x1944),25fps@4MP(2592x1520),25fps@3MP/1080P/720P Sub Stream: VGA(640x480)/360P/QVGA@25fps, etc. |
|
Video Bitrates |
32Kbps - 8Mbps, VBR/CBR |
|
Audio Standard |
G.711-u/G.711-a |
|
OSD Overlay |
Title and Time overlay |
|
IR Led |
6pcs SMD IR Led |
|
IR Distance |
20-30 M |
|
Focal length |
2.8 -12 mm AF lens |
|
Zoom |
4x optical zoom |
|
Optional Function |
POE, Audio, etc. |
|
Pan/Tilt Range |
Pan: 0° ~ 180°; Tilt: -0.5° ~ 55° |
|
Preset Point |
1 |
|
Manual Control Speed |
Pan: 0.5° ~15° /s; Tilt: 0.5° ~15° /s |
|
Guard Position |
Support |
|
Power-off Recovery |
Support |
|
Protocol |
HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc. |
|
P2P |
Yes |
|
Web |
IE , Firefox esr, etc. |
|
Media |
CMS, Android, IOS |
|
ONVIF |
17.06 compatible |
|
Network Port |
1-RJ45, 100Mbps, POE optional |
|
Power Supply |
12 VDC ± 10% |
|
Power Consumption |
< 12 W |
|
Operating Temp. |
-20-(+60), 10%-90%RH |
|
