1. ESC: Return to the previous interface.
2. SETUP: Press the button to get into the system setting of the keyboard.It includes 5 options：Network Mode,Sound,Language,Password and Default.You can use the joystick to choose the option.
Network Mode: It includes two options(Static and DHCP) that you can
choose it through the joystick(left or right) .You need to press the button
"OK" after you choose the option.
Sound: You can choose if open the sound of the keyboard through the
Joystick(left or right).You need to press the button "OK" after you choose
the option.
Language: You can choose the language you want through the joystick(left
or right).You need to press the button "OK" after you choose the option.
Password: Setup the keyboard's password(press "OK" to work after you
choose the option).The default password is"1234".
Default:It will restore your keyboard setting to default(press "OK" to
work after you choose the option).
3. Inquiry:You can view the client list by press the button.
4. Lock: Press the button then your keyboard system will be locked.Press it again
and then input the password,it will be unlocked.
5. Single: Single view or one split view key. Press it to turn on/off current
window or camera in single widow mode.
6. Full: Full screen key. Press it to turn on/off full screen mode..
7. Views:Press the button and then input the number for the split views
that you want to show.
8. CAM:Press the button and then input camera number that you set in the
NVSS/NVMS(PTZ Keyboard Setting) as pic2,it will show the camera with single
view.
9. Win+:Press the button to select the next window.
10. Win-:Press the button to select the last window.
11. Group:Press the button and then input group number that you set in the
NVSS or NVMS,it will show the group in the preview.
12. MON:Press the button and then input the monitor number(you can view the
number in the PTZ Keyboard Setting-->Monitor Setting of NVSS/NVMS) as
pic3,then you can control the monitor you choose.
13. Title:Press the button to show or hide all video title.
14. REC.:Press the button to make all record type switch to manual record.Press it
again to restore.
15. Grab:Press the button to grab the current image.
16. Tours:Please selected the PTZ camera first and then press the button to input
the TourGroup number that you had set in the NVSS/NVMS.
17. Alarm On:Press the button to enable the alarm camera popup.
18. Alarm Off:Press the button to disable the alarm camera popup.
19. Inst Play:Press the button to input the number(1-9),and then it will instant
playback current window (1~9)minutes.Press the "Stop" button to exit playback.If
you input "0",it will get into local playback.
20. Set Preset:Please selected the PTZ camera first.Press the button and then input
number to set the preset.
21. Clear Preset:Please selected the PTZ camera first.Press the button and then
input number to clear the preset.
22. Call Preset:Please selected the PTZ camera first.Press the button and then
input number to call the preset.
23. Focus+, Focus-:Press it to adjust the focus of active camera's lens.
24. Zoom in, Zoom out:Zoom function of the PTZ camera control.
25. Iris+,Iris-:Overrides the PTZ cameras auto-iris and brighten or darken the
Image.
26. Auto Pan,Wiper,Relay:It can not working now,please wait for the
function update.....
27. Joystick:Please selected the PTZ camera first.You can move up, down, left,
right as well as other directions by rocking the joystick.
